This product image represents a base model and is for identification purposes only.
Magnetic Motor Starter, Nema Size 2, 45 Amps, 3 Poles, Non-Reversing, 120VAC Coil at 60HZ, Full Voltage 600VAC, Overload Protection Standard, Open Style No Enclosure, Across the Line Starting and Stopping, Advantage Series, Smaller Physical Size Than Other Types, Max HP Ratings: 10 @ 200 Motor Volts AC, 15 @ 230 Motor Volts AC, 25 @ 460/575 Motor Volts AC, Motor FLA (1.15-1.25 S.F.) 3.15-45.00 and (1.0 S.F.) 3.43-45.00.
Product Description
Magnetic Motor Starter, Nema Size 2, 45 Amps, 3 Poles, Non-Reversing, 120VAC Coil at 60HZ, Full Voltage 600VAC, Overload Protection Standard, Open Style No Enclosure, Across the Line Starting and Stopping, Advantage Series, Smaller Physical Size Than Other Types, Max HP Ratings: 10 @ 200 Motor Volts AC, 15 @ 230 Motor Volts AC, 25 @ 460/575 Motor Volts AC, Motor FLA (1.15-1.25 S.F.) 3.15-45.00 and (1.0 S.F.) 3.43-45.00.
Specifications
| Manufacturer | Eaton / Cutler Hammer |
|---|---|
| Warranty | One Year |
| Amperage | 45 |
| Coil Voltage | 120VAC |
| Phase | 3 |
| Voltage Max | 600 |
| Nema Size | 2 |
| Coil Type | Magnetic |
| Reversing or Non-Reversing | Non-Reversing |
| Maximum Ratings | 10 @ 200 Motor Volts AC, 15 @ 230 Motor Volts AC, 25 @ 460/575 Motor Volts AC |
| Application | Full Voltage |
| Style | Advantage |
| Poles | 3 |
