Westinghouse: Circuit Breakers

Product Description Specs are as follows: PBF Frame Style, Molded-Case Circuit Breaker, Thermal Magnetic Interchangeable Trip Unit, 900 Ampere at 40 Degree Celsius, 3 Pole, 600VAC @ 50/60HZ, Interrupting Ratings: 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC, Front Connected, Frame Rated at 2000 Ampere, 900A Trip Unit Installed, Without Terminals Standard. This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Connection Front Frame Type PB Amperage 900 Poles 3 Voltage Max 600 Interrupting Capacity Rating 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC Trip Setting Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: PBF Frame Style, Molded-Case Circuit Breaker, Thermal Magnetic Interchangeable Trip Unit, 700 Ampere at 40 Degree Celsius, 3 Pole, 600VAC @ 50/60HZ, Interrupting Ratings: 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC, Front Connected, 700A Trip Unit Installed, Frame Rated at 2000 Ampere. Without Terminals. This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Connection Front Frame Type PB Amperage 700 Poles 3 Voltage Max 600 Interrupting Capacity Rating 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC Trip Setting Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: PB Frame Style, Molded-Case Circuit Breaker, Thermal Magnetic Interchangeable Trip Unit, Frame Only, 3 Pole, 600VAC @ 50/60HZ, Interrupting Ratings: 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC, Rear Connected, 3000A Trip Unit Installed, Frame Rated at 3000 Ampere, Without Terminals Standard. This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Connection Frame Type PB Amperage 3000A Max Poles 3 Voltage Max 600 Interrupting Capacity Rating 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: PB Frame Style, Molded-Case Circuit Breaker, Thermal Magnetic Interchangeable Trip Unit, 900 Ampere at 40 Degree Celsius, 3 Pole, 600VAC @ 50/60HZ, Interrupting Ratings: 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC, Rear Connected, 900A Trip Unit, Frame Rated at 2000 Ampere, Without Terminals Standard. This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Connection Rear Frame Type PB Amperage 900 Poles 3 Voltage Max 600 Interrupting Capacity Rating 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC Trip Setting Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: PB Frame Style, Molded-Case Circuit Breaker, Thermal Magnetic Interchangeable Trip Unit, 700 Ampere at 40 Degree Celsius, 3 Pole, 600VAC @ 50/60HZ, Interrupting Ratings: 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC, Rear Connected, 700A Trip Unit Installed, Frame Rated at 2000 Ampere, Without Terminals Standard. This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Connection Rear Frame Type PB Amperage 700 Poles 3 Voltage Max 600 Interrupting Capacity Rating 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC Trip Setting Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: PB Frame Style, Molded-Case Circuit Breaker, Thermal Magnetic Interchangeable Trip Unit, 2000 Ampere at 40 Degree Celsius, 3 Pole, 600VAC @ 50/60HZ, Interrupting Ratings: 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC, Rear Connected, 2000A Trip Unit, Frame Rated at 2500 Ampere, Without Terminals Standard. This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Connection Frame Type PB Amperage 2000 Poles 3 Voltage Max 600 Interrupting Capacity Rating 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC Trip Setting Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: PB Frame Style, Molded-Case Circuit Breaker, Thermal Magnetic Interchangeable Trip Unit, 1800 Ampere at 40 Degree Celsius, 3 Pole, 600VAC @ 50/60HZ, Interrupting Ratings: 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC, Rear Connected, 1800A Trip Unit, Frame Rated at 2500 Ampere, Without Terminals Standard. This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Connection Frame Type PB Amperage 1800 Poles 3 Voltage Max 600 Interrupting Capacity Rating 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC Trip Setting Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: PB Frame Style, Molded-Case Circuit Breaker, Thermal Magnetic Interchangeable Trip Unit, 1600 Ampere at 40 Degree Celsius, 3 Pole, 600VAC @ 50/60HZ, Interrupting Ratings: 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC, Rear Connected, 1600A Trip Unit, Frame Rated at 2500 Ampere, Without Terminals Standard. This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Connection Frame Type PB Amperage 1600 Poles 3 Voltage Max 600 Interrupting Capacity Rating 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC Trip Setting Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: PB Frame Style, Molded-Case Circuit Breaker, Thermal Magnetic Interchangeable Trip Unit, 1400 Ampere at 40 Degree Celsius, 3 Pole, 600VAC @ 50/60HZ, Interrupting Ratings: 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC, Rear Connected, 1400A Trip Unit, Frame Rated at 2500 Ampere, Without Terminals Standard. This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Connection Frame Type PB Amperage 1400 Poles 3 Voltage Max 600 Interrupting Capacity Rating 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC Trip Setting Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: PB Frame Style, Molded-Case Circuit Breaker, Thermal Magnetic Interchangeable Trip Unit, 1200 Ampere at 40 Degree Celsius, 3 Pole, 600VAC @ 50/60HZ, Interrupting Ratings: 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC, Rear Connected, 1200A Trip Unit, Frame Rated at 2500 Ampere, Without Terminals Standard. This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Connection Frame Type PB Amperage 1200 Poles 3 Voltage Max 600 Interrupting Capacity Rating 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC Trip Setting Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: PB Frame Style, Molded-Case Circuit Breaker, Thermal Magnetic Interchangeable Trip Unit, 1000 Ampere at 40 Degree Celsius, 3 Pole, 600VAC @ 50/60HZ, Interrupting Ratings: 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC, Rear Connected, 1000A Trip Unit, Frame Rated at 2500 Ampere, Without Terminals Standard. This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Connection Frame Type PB Amperage 1000 Poles 3 Voltage Max 600 Interrupting Capacity Rating 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC Trip Setting Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: PB Frame Style, Molded-Case Circuit Breaker, Thermal Magnetic Interchangeable Trip Unit, 900 Ampere at 40 Degree Celsius, 3 Pole, 600VAC @ 50/60HZ, Interrupting Ratings: 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC, Rear Connected, 900A Trip Unit, Frame Rated at 2500 Ampere, Without Terminals Standard. This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Connection Frame Type PB Amperage 900 Poles 3 Voltage Max 600 Interrupting Capacity Rating 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC Trip Setting Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: PB Frame Style, Molded-Case Circuit Breaker, Thermal Magnetic Interchangeable Trip Unit, 800 Ampere at 40 Degree Celsius, 3 Pole, 600VAC @ 50/60HZ, Interrupting Ratings: 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC, Rear Connected, 800A Trip Unit, Frame Rated at 2500 Ampere, Without Terminals Standard. This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Connection Frame Type PB Amperage 800 Poles 3 Voltage Max 600 Interrupting Capacity Rating 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC Trip Setting Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: PB Frame Style, Molded-Case Circuit Breaker, Thermal Magnetic Interchangeable Trip Unit, 700 Ampere at 40 Degree Celsius, 3 Pole, 600VAC @ 50/60HZ, Interrupting Ratings: 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC, Rear Connected, 700A Trip Unit, Frame Rated at 2500 Ampere, Without Terminals Standard. This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Connection Frame Type PB Amperage 700 Poles 3 Voltage Max 600 Interrupting Capacity Rating 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC Trip Setting Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: PB Frame Style, Molded-Case Circuit Breaker, Thermal Magnetic Interchangeable Trip Unit, 600 Ampere at 40 Degree Celsius, 3 Pole, 600VAC @ 50/60HZ, Interrupting Ratings: 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC, Rear Connected, 600A Trip Unit, Frame Rated at 2500 Ampere, Without Terminals Standard. This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Connection Frame Type PB Amperage 600 Poles 3 Voltage Max 600 Interrupting Capacity Rating 125 Kiloampere @ 240VAC, 100 Kiloampere @ 480VAC, 100 Kiloampere @ 600VAC Trip Setting Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: NCGA Frame Style, Frame Only, Molded Case Circuit Breaker, LSIG Function Non-Interchangeable Trip Unit, 3 Pole, 600VAC @ 50/60HZ, Interrupting Ratings: 42 Kiloampere @ 240VAC, 30 Kiloampere @ 480VAC, 22 Kiloampere @ 600VAC, No Rating Plug Installed, 1200A Maximum Frame Size, Without Terminals Standard. L – Adjustable Long Delay Pickup (By Adjustable Rating Plug) S – Adjustable Short Delay Pickup with Fixed Short Delay Time (I2t Response) or Adjustable Short Time (Flat Response) I – Adjustable Instantaneous Pickup by Setting Short Time Delay Time to Instantaneous G – Adjustable Ground Fault Pickup with Adjustable Ground Fault Delay (Flat Response) This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Connection Bolt On Frame Type NCGA Amperage 1200A Max Poles 3 Voltage Max 600 VAC Interrupting Capacity Rating 42 Kiloampere @ 240VAC, 30 Kiloampere @ 480VAC, 22 Kiloampere @ 600VAC Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: NCG Frame Style, Molded Case Circuit Breaker, LSG Function Non-Interchangeable Trip Unit, 3 Pole, 600VAC @ 50/60HZ, High Interrupting Style, Interrupting Ratings: 42 Kiloampere @ 240VAC, 30 Kiloampere @ 480VAC, 22 Kiloampere @ 600VAC , 600A Rating Plug Installed, 1200A Maximum Frame Size, Without Terminals Standard. L – Adjustable Long Delay Pickup (By Adjustable Rating Plug) S – Adjustable Short Delay Pickup with Fixed Short Delay Time (I2t Response) or Adjustable Short Time (Flat Response) G – Adjustable Ground Fault Pickup with Adjustable Ground Fault Delay (Flat Response) This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse / Cutler-Hammer Warranty One Year Configuration 12NC600 Frame Type NC Amperage 600 Poles 3 Voltage Max 600 Interrupting Capacity Rating 42 Kiloampere @ 240VAC, 30 Kiloampere @ 480VAC, 22 Kiloampere @ 600VAC Trip Setting 1,200-4,800 Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: NCG Frame Style, Frame Only, Molded Case Circuit Breaker, LSG Function Non-Interchangeable Trip Unit, 3 Pole, 600VAC @ 50/60HZ, High Interrupting Style, Interrupting Ratings: 42 Kiloampere @ 240VAC, 30 Kiloampere @ 480VAC, 22 Kiloampere @ 600VAC , No Rating Plug Installed, 1200A Maximum Frame Size, Without Terminals Standard. L – Adjustable Long Delay Pickup (By Adjustable Rating Plug) S – Adjustable Short Delay Pickup with Fixed Short Delay Time (I2t Response) or Adjustable Short Time (Flat Response) G – Adjustable Ground Fault Pickup with Adjustable Ground Fault Delay (Flat Response) This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse / Cutler-Hammer Warranty One Year Frame Type NC Amperage 1200A Max Poles 3 Voltage Max 600 Interrupting Capacity Rating 42 Kiloampere @ 240VAC, 30 Kiloampere @ 480VAC, 22 Kiloampere @ 600VAC Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: NCA Frame Style, Molded Case Circuit Breaker, LSI Function Non-Interchangeable Trip Unit, 3 Pole, 600VAC @ 50/60HZ, Interrupting Ratings: 42 Kiloampere @ 240VAC, 30 Kiloampere @ 480VAC, 22 Kiloampere @ 600VAC, No Rating Plug Installed, 1200A Maximum Frame Size, Without Terminals Standard. L – Adjustable Long Delay Pickup (By Adjustable Rating Plug) S – Adjustable Short Delay Pickup with Fixed Short Delay Time (I2t Response) or Adjustable Short Time (Flat Response) I – Adjustable Instantaneous Pickup by Setting Short Time Delay Time to Instantaneous This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Connection Frame Type NCA Amperage 1200A Max Poles 3 Voltage Max 600 VAC Interrupting Capacity Rating 42 Kiloampere @ 240VAC, 30 Kiloampere @ 480VAC, 22 Kiloampere @ 600VAC Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: NC Frame Style, Frame Only, Molded Case Circuit Breaker, Mag Only Non-Interchangeable Trip Unit, 3 Pole, 600VAC @ 50/60HZ, High Interrupting Style, Interrupting Ratings: 42 Kiloampere @ 240VAC, 30 Kiloampere @ 480VAC, 22 Kiloampere @ 600VAC , No Rating Plug Installed, 1200A Maximum Frame Size, Without Terminals Standard. This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Connection Bolt On Frame Type NC Amperage 1200A Max Poles 3 Voltage Max 600 VAC Interrupting Capacity Rating 42 Kiloampere @ 240VAC, 30 Kiloampere @ 480VAC, 22 Kiloampere @ 600VAC Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: NC Frame Style, Molded Case Circuit Breaker, LS Function Non-Interchangeable Trip Unit, 3 Pole, 600VAC @ 50/60HZ, Interrupting Ratings: 42 Kiloampere @ 240VAC, 30 Kiloampere @ 480VAC, 22 Kiloampere @ 600VAC , 600A Rating Plug Installed, 1200A Maximum Frame Size, Without Terminals Standard. L – Adjustable Long Delay Pickup (By Adjustable Rating Plug) S – Adjustable Short Delay Pickup with Fixed Short Delay Time (I2t Response) or Adjustable Short Time (Flat Response) This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Configuration 12NC600 Connection Bolt On Frame Type NC Amperage 600 Poles 3 Voltage Max 600 VAC Interrupting Capacity Rating 42 Kiloampere @ 240VAC, 30 Kiloampere @ 480VAC, 22 Kiloampere @ 600VAC Trip Setting 1,200-4,800 Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: NC Frame Style, Molded Case Circuit Breaker, Mag Only Non-Interchangeable Trip Unit, 3 Pole, 600VAC @ 50/60HZ, High Interrupting Style, Interrupting Ratings: 42 Kiloampere @ 240VAC, 30 Kiloampere @ 480VAC, 22 Kiloampere @ 600VAC , 600A Rating Plug Installed, 1200A Maximum Frame Size, Without Terminals Standard. This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Configuration 12NC600 Connection Bolt On Frame Type NC Amperage 600 Poles 3 Voltage Max 600 VAC Interrupting Capacity Rating 42 Kiloampere @ 240VAC, 30 Kiloampere @ 480VAC, 22 Kiloampere @ 600VAC Trip Setting 1,200-4,800 Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: NC Frame Style, Frame Only, Molded Case Circuit Breaker, LS Function Non-Interchangeable Trip Unit, 3 Pole, 600VAC @ 50/60HZ, Interrupting Ratings: 42 Kiloampere @ 240VAC, 30 Kiloampere @ 480VAC, 22 Kiloampere @ 600VAC , No Rating Plug Installed, 1200A Maximum Frame Size, Without Terminals Standard. L – Adjustable Long Delay Pickup (By Adjustable Rating Plug) S – Adjustable Short Delay Pickup with Fixed Short Delay Time (I2t Response) or Adjustable Short Time (Flat Response) This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Connection Bolt On Frame Type NC Amperage 1200A Max Poles 3 Voltage Max 600 VAC Interrupting Capacity Rating 42 Kiloampere @ 240VAC, 30 Kiloampere @ 480VAC, 22 Kiloampere @ 600VAC Standard Lug Type Without Terminals Standard

Product Description Specs are as follows: HNCGA Frame Style, Molded Case Circuit Breaker, Mark 75, LSIG Function Non-Interchangeable Trip Unit, High Interrupting Capacity, 3 Pole, 600VAC @ 50/60HZ, High Interrupting Style, Interrupting Ratings: 65 Kiloampere @ 240VAC, 50 Kiloampere @ 480VAC, 25 Kiloampere @ 600VAC, No Rating Plug Installed, 1200A Maximum Frame Size, Without Terminals Standard. L – Adjustable Long Delay Pickup (By Adjustable Rating Plug) S – Adjustable Short Delay Pickup with Fixed Short Delay Time (I2t Response) or Adjustable Short Time (Flat Response) I – Adjustable Instantaneous Pickup by Setting Short Time Delay Time to Instantaneous G – Adjustable Ground Fault Pickup with Adjustable Ground Fault Delay (Flat Response) This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout. Specifications Manufacturer Westinghouse Warranty One Year Connection Bolt On Frame Type HNC Amperage 1200A Max Poles 3 Voltage Max 600 VAC Interrupting Capacity Rating 65 Kiloampere @ 240VAC, 50 Kiloampere @ 480VAC, 25 Kiloampere @ 600VAC Standard Lug Type Without Terminals Standard
