Product Description
Specs are as follows:
THJK Hi-Break Frame Style, Molded Case Circuit Breaker, Thermal Magnetic Interchangeable Trip Unit, 500 Ampere at 40 Degree Celsius, 3 Pole, 600VAC @ 50/60HZ, Interrupting Ratings: 65 Kiloampere @ 240V AC, 35 Kiloampere @ 480V AC, 25 Kiloampere @ 600V AC, 40 Kiloampere @ 250V DC, Line and Load End Terminals Standard.
Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout.
Specifications
| Manufacturer | General Electric GE |
|---|---|
| Warranty | One Year |
| Connection | Bolt On |
| Frame Type | J |
| Amperage | 500 |
| Poles | 3 |
| Voltage Max | 600 |
| Interrupting Capacity Rating | 65 Kiloampere @ 240V AC, 35 Kiloampere @ 480V AC, 25 Kiloampere @ 600V AC, 40 Kiloampere @ 250V DC |
| Trip Setting | 1500-5000 |
| Standard Lug Type | Line and Load |
