HMCPE100R3C
Product Description
Motor Circuit Protector (MCP), EG Frame Style, Molded Case Circuit Breaker, Magnetic Non-interchangeable Trip Unit, Instantaneous-only, 100 Amperes, 3 Pole, 300-1100 Trip Setting, Motor Full Load Current Amperes 23.0-87.0, Non-aluminum Body Terminals Standard, 600Y/377VAC, 250VDC Maximum.
This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout.
Specifications
| Manufacturer | Eaton / Cutler Hammer |
|---|---|
| Warranty | One Year |
| Connection | Bolt On |
| Frame Type | EG |
| Amperage | 100 |
| Poles | 3 |
| Voltage Max | 600 |
| Trip Setting | 300-1100 |
| Motor FLA | 23.0-87.0 |
New Surplus
Certified Reconditioned
