HKAM3225 1125-2250 THERMAL-MAG WUVR

Certified Reconditioned

Qty in Stock: 2

$1,750.00

Product Description

Specs are as follows:

K Frame Style, Molded Case Mining Circuit Breaker, Non-Interchangeable Thermal-Magnetic Trip Unit, 225 Ampere at 40 Degree Celsius, 3 Pole, 1000VAC @ 50/60HZ, Interrupting Ratings: 10 Kiloampere @ 1000VAC, 120v UVR installed, No Lugs Standard.

Other prebuilt configurations available:

HKAM3225 1125-2250 THERMAL-MAG

Specifications


Manufacturer Westinghouse
Warranty One Year
Configuration 120v UVR
Connection Bolt On
Frame Type K
Amperage 225
Poles 3
Voltage Max 1000
Interrupting Capacity Rating 10 Kiloampere @ 1000VAC
Trip Setting 1125-2250
Standard Lug Type No Lugs Standard
