EH3B100
Product Description
EH Frame Style, Molded Case Circuit Breaker, Thermal Magnetic Non-interchangeable Trip Unit, 100 Ampere at 40 Degree Celsius, 3 Pole, 240VAC and 480VAC @ 50/60HZ, Interrupting Ratings: 18 Kiloampere @ 240VAC, 14 Kiloampere @ 480VAC, Line and Load End Terminals Standard.
This product image represents a base model and is for identification purposes only. Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout.
Specifications
| Manufacturer | Siemens / ITE |
|---|---|
| Warranty | One Year |
| Connection | Bolt On |
| Frame Type | EH |
| Amperage | 100 |
| Poles | 3 |
| Voltage Max | 480 |
| Interrupting Capacity Rating | 65 Kiloampere @ 240VAC, 18 Kiloampere @ 480VAC |
| Standard Lug Type | Load End Only |
New Surplus
Certified Reconditioned
Qty in Stock: 2
$1,495.00
Couldn't load pickup availability
