Look under Parts & Accessories or follow the links below to order accessories used to create additional configurations for this unit.
1. Auxiliary Switches
2. Shunt Trips
3. Undervoltage Releases (UVRs)
4. Terminal/Lug Kits
Are you purchasing accessories and your breaker in the same order? We will install your accessories to meet your specific configuration needs at NO ADDITIONAL COST! Just provide the necessary information in the order comment box during checkout.
Product Description
ED Frame Style, Molded Case Circuit Breaker, Thermal Magnetic Non-interchangeable Trip Unit, 40 Ampere at 40 Degree Celsius, 3 Pole, 240VAC @ 50/60HZ, Interrupting Ratings: 10 Kiloampere @ 240VAC.
Specifications
| Manufacturer | Siemens / ITE |
|---|---|
| Warranty | One Year |
| Connection | Bolt On |
| Frame Type | ED |
| Amperage | 40 |
| Poles | 3 |
| Voltage Max | 240 |
| Interrupting Capacity Rating | 10 Kiloampere @ 240VAC |
